What is Rebar? Types and Grades of Steel Reinforcement

Reading time: 1 minute

What is Rebar?

Steel reinforcement bars or rebars are used to improve the tensile strength of the concrete, since concrete is very weak in tension, but is strong in compression. Steel is only used as rebar because elongation of steel due to high temperatures (thermal expansion coefficient) nearly equals to that of concrete.

Fig 1: Reinforcement Steel Bar

Grades of Rebar in Different Codes

Table 1: Grades of Rebar in Different Codes
American Standard (ASTM A 615) Euro Standard(DIN 488) British Standard BS4449: 1997 Indian Standard (IS: 1786)
Grade 75 (520) BST 500 S GR 460 A Grade Fe – 415, Fe – 500, Fe – 500D
Grade 80 (550) BST 500 M GR 460 B Grade Fe – 550

Types of Steel Reinforcement Bars

Major types of steel bars used in the construction are as follows,

1. Mild Steel Bar

The surface of the mild steel bars are plain and round in shape. They are available in various sizes of 6 mm to 50 mm. They are used in concrete for special purposes, such as dowels at expansion joints, where bars must slide in a metal or paper sleeve, for contraction joints in roads and runways, and for column spirals. They are easy to cut and bend without damage.

Fig 2 : Mild Steel Bar

For structural buildings like bridges and other heavy structures, mild steel bar is not recommended due to no great bonding between concrete and steel, slippage and strength.

Grades in mild steel bars

1. Mild Steel Bars
  • Mild steel bars grade-I designated as Fe 410-S or Grade 60.
  • Mild steel bars grade-II designated as Fe-410-o or Grade 40.
2. Medium Tensile Steel Bars designated as Fe- 540-w-ht or Grade 75.

Physical Requirement of Mild Steel Bars

Table 2:Physical Requirement of Mild Steel Bars
Types of Nominal size of bar Ultimate Tensile Stress in N/mm2 Yield Stress N/mm2 Elongation Percentage min
Mild Steel Grade I or Grade 60
For Bars upto 20mm 410 250 23
For Bars above 20mm upto 50mm 410 240 23
Mild Steel Grade II or Grade 40
For Bars upto 20mm 370 225 23
For Bars above 20mm upto 50mm 370 215 23
Medium Tensile Steel Grade -75
For Bars upto 16mm 540 350 20
For Bars above 16mm upto 32mm 540 340 20
For Bars above 32mm upto 50mm 510 330 20

2. Deformed Steel Bar

Deformed steel bars have ribs, lugs and indentation on the surface of the bar, which reduces the major problem that is faced by mild steel bar due to slippage and good bonding is achieved between concrete and rebar. The tensile properties is higher compared to other rebars. These bars are produced in sections from 6 mm to 50 mm dia.

Types of Deformed Steel Bars

1. TMT Bars (Thermo Mechanically Treated Bars)

Thermo Mechanically Treated Bars are hot treated bars that are high in strength used in reinforced cement concrete (RCC) work. It is the latest induction in the MS steel bars with superior properties such as strength, ductility, welding ability, bending ability and highest quality standards at international level.

Fig 3: Deformed TMT Steel Bar

Characteristics of TMT Rebars

  • Better ductility and malleability
  • High yield strength and toughness
  • More bonding strength
  • Earthquake resistance
  • Corrosion resistance
  • High thermal resistance
  • Economical and safe in use
  • No loss in strength at welded joints
  • Ordinary electrodes used for welding the joints

2. High Strength Deformed Bars

High strength deformed bars are cold twisted steel bars with lugs, ribs, projection or deformation on the surface. It the extensively and majorly used for reinforcement purposes in a construction. These bars are produced in sizes or sections from 4 mm to 50 mm in diameter.

Fig 4: Deformed HSD Steel Bar

Characteristics of HSD Rebar

  • Low carbon value - HSD Bars have lower carbon level, resulting in good ductility, strength and welding ability.
  • Superior bonding strength - HSD bars are well known for their excellent bonding strength when used with concrete.
  • Welding capability - Since these bars have lower carbon content, they have 100% welding capability than conventional bars.
  • High tensile strength - HSD bars feature high tensile strength. They offer great asset in construction process, where a lot of bending and re bending is required.
  • Wide application range - These bars have wide application range like in building residential, commercial and industrial structures, bridges, etc.
  • Satisfactorily malleability - Minimum weight and maximum strength and suitable for both compression and tension reinforcement.

3. Other Types of Rebars

Depending upon the type of material used in the production of rebar, different types of rebars are

1. European Rebar

European rebar is made of manganese, which makes them bend easily. They're not suitable for use in areas that are prone to extreme weather conditions or geological effects, such as earthquakes, hurricanes, or tornadoes. The cost of this rebar is low.

2. Carbon Steel Rebar

As the name represents, it is made up of carbon steel and is commonly known as Black Bar due to carbon colour. The main drawback of this rebar is that it corrodes, which adversely effect the concrete and structure.  The tensile strength ratio coupled with the value makes black rebar one of the best choices.

Fig 5: Carbon Steel Rebar

3. Epoxy-Coated Rebar

Epoxy-coated rebar is black rebar with an epoxy coat. It has the same tensile strength, but is 70 to 1,700 times more resistant to corrosion. However, the epoxy coating is incredibly delicate. The greater the damage to the coating, the less resistant to corrosion.

Fig 6: Epoxy-Coated Rebar

4. Galvanized Rebar

Galvanized rebar is only forty times more resistant to corrosion than black rebar, but it is more difficult to damage the coating of galvanized rebar. In that respect, it has more value than epoxy-coated rebar. However, it is about 40% more expensive than epoxy-coated rebar.

Fig 7: Galvanized Rebar

5. Glass-Fiber-Reinforced-Polymer (GFRP)

GFRP is made up of carbon fibre. As it is made up of fibre, bending is not allowed. It is very resistant to corrosion and is costly when compared to other rebars.

Fig 8: Glass-Fiber-Reinforced-Polymer Rebar

6. Stainless Steel Rebar

Stainless steel rebar is the most expensive reinforcing bar available, about eight times the price of epoxy-coated rebar. It is also the best rebar available for most projects. However, using stainless steel in all but the most unique of circumstances is often overkill. But, for those who have a reason to use it, stainless steel rebar 1,500 times more resistant to corrosion than black bar; it is more resistant to damage than any of the other corrosive-resistant or corrosive-proof types or rebar; and it can be bent in the field.
